BEMO seam metal roof roll forming machine
It is mostly used as a decorative cover on the roof of railway stations, high-speed rail stations, stadiums, convention centers, museums and other buildings...
TEL : +86 13231741939
DETAILS
Product Overview
YX65-330/430/580 Standing Seam Roll Forming Machine
The finished product produced by the 430 aluminum magnesium manganese version equipment is "YX65-430" aluminum magnesium manganese roof panel. It is mostly used as a decorative cover on the roof of railway stations, high-speed rail stations, stadiums, convention centers, museums and other buildings.
This machine is specially customized; it is used for arc bending of finished plates. The curved panels are widely used in various modeling buildings, stadiums, high-speed railway stations, museums, and so on.The whole machine includes 5 tons bearing weight decoiler, feeding platform,forming,cutting,sector part which will be realize electrified control, convenient and quick operation, improve production efficiency, and reduce labor intensity.
FEATURES AT A GLANCE
PRODUCT SPECIFICATIONS
MACHINE COMPONENTS
NO. Description Quantity (set)
1 5T hydraulic decoiler 1
2 Guiding device 1
3 Forming system with ribs1
4 Transmission system 1
5 Hydraulic guillotine 1
6 Support table 1
7 Hydraulic pump station 1
8 Control box 1
9 Spare parts and tools 1
10 electric seamer1
PRODUCT CONFIGURATION
Feeding platform：
Based on the right feeding platform, different feeding widths can be adjusted by adjusting the screws and nuts on the left platform. Enter the forming section with the left edge of the material in line with the left wheel.
Forming rollers:
14 sets
42CrMo4 alloy steel finishing heat treatment hard chromium plating
Electric control cabinet:
Cantilever type :save workshop space
Delta brans or XIEJIE brand or customzied brands
Hydraulic pump station and motor :
4kw hydraulic pump station with cooling fan which can redece the oil temperature when machine working
Automatic hydraulic cutting
cutting stable without burrs
5T hydraulic decoiler
1.Host volume: length 2.4 meters, width 1.55 meters, height 1.75 meters
2.Host weight: about 1.3 ton
3.Hydraulic pumping station: 5 solenoid valve pumping stations (the pump valve is Beijing Huade brand), power 3kw 380V
4.C-shaped steel: no power, passive feeding, hydraulic tensioning
5.Frame body: the base is made of 80*160*5 square tube, and the box body is welded with 12mm thick steel plate
6.Main shaft for supporting material: thick-walled seamless steel pipe is machined, and the shaft diameter is 133*25mm
7.Feeding width: 0-650mm
8.Inner diameter of steel coil: 470-700mm, ±20mm
9. The rated load capacity is within 5 tons
10. Hydraulic cylinder: expansion cylinder bore diameter 110mm, 1 piece (plus rotation) 11. Hydraulic pressing arm (Jinda) advantage: 1. The load-bearing spindle is made of high-strength, fatigue-resistant rear wall seamless steel, which is processed by turning, with strong strength and heavy bearing. 2. The roll up adopts hydraulic control, which is convenient, fast and stable.
Run out table
receiving tables
3 pieces
SALES AND SERVICE NETWORK
Successful Project
Projectin USA
Project in RUSSIA
Project in ALGERIA
SIMILAR PRODUCTS
PACKING AND SHIPPING
EXHIBITION AND CLIENTS
SAMPLE ROOM
FAQ
1. Package
1). Container packing of the line suitable for overseas shipping
2). The subjects can be loaded by LCL shipping.3). Package style: Covered by plastic film, spare parts and some small parts packed in carton box.
2. Delivery Time25-30 days (not include Chinese holiday) from order acceptance, deposit receipt and technical details agreement.
3. Payment30% paid by T/T as deposit, 70% paid by T/T before loading.
4. Quality Warranty 15 months from time of loading by seller quality guarantee, life guarantee repair. Within quality guarantee period, except for failures caused by human error, repair parts will be provided for free. After the quality guarantee period, only charge the production cost of the spare parts.Free technical supporting and maintenance consulting in lifetime.
5. Assembly (Optional)
1). Machine will be tested completely in working before delivery to you.After receiving the machine and just need to connect the main power wires and can start to work. I will send you operation video , operation manual,too. very easy to operate.
2). If you need engineer overseas serviceas, the installation charge can be discuss with Elena Whastapp 0086-13231741939 If you need engineer overseas services, the buyer has to pay the seller’s technician: Travel cost outside China (Including round flight charges), accommodation and foods (At least three-star hotel with air condition), solve the language problem, provide transportation from living place to the work place, and insurance out of China, etc.
WHY CHOOSE US?
Point 1: We are a big factory which has been developed 12 years. During the 12 years, we service each customers sincerity.
Point 2: Our company has great engineers who can design your profile perfectly. If you want to do a better machine, the first thing is to do a better design for profiles. We are a big and old factory so we have enough experience for designing the profiles.
Point 3: I am a very easy-going female salesperson, please tell me all your requirements for the machine, I can do my best to meet your needs. I can give you the best after-sale services. The machine is customized .So, about the machines' prices which have many .We can do your needed machine according to your request.
Point 4: About the machines' production, we have more than 50 machine making workers in our workshop and we have more than 20 sets of CNC machines to do processing rollers, shafts, base frames , cutters......About the machine making time, we guarantee you .
Point 5: About the machine acceptance , we can make videos and you see the machine running through videos . And also i will shoot the machine's opertaion video, connection video to you. Before machine loading, i will send you all necessary documemnts: operation video , wires connected videos, wiring diagram, floor diagram, oil circuit diagram, operation manual .....If necessary, we can send engineer to your there. No worries about the machine usage. We give you the best after-sale services.
Point 6: The warranty time is 15 months from the machine delivery from our factory. During the period, any problems about the machine, we replace the spare parts and helping you to solve problems freely. Exceed this period, we will also solve the problems freely for you , if need to replace some spare parts, only charge the spare parts and freight for you. Solving problems through videos is free for you. We give you the best after sale services.
Point 7：About the shipment, we have several long cooperated forwarder who can quote us the lowest sea freight . if you need us to ship for you, i can give u the best suitable sea freight . You don't need to worry about you can not deal with the shipment. Also , you can choose your own forwarder and I will cooperate with them throughout.
