Automatic D style metal roof drip edge roll forming machine roof drip edge roll former
A Drip Edge Roll Forming Machine is a specialized piece of equipment used in the construction and roofing industry to produce drip edges, which are essential components for roof installations...
TEL : +86 13231741939
DETAILS
Product Overview
D-METAL T STYLE DRIP EDGE ROLL FORMING MACHINE
A Drip Edge Roll Forming Machine is a specialized piece of equipment used in the construction and roofing industry to produce drip edges, which are essential components for roof installations. Drip edges are metal strips that are installed along the edges of a roof to protect it from water damage and help direct rainwater away from the structure. These machines automate the process of manufacturing drip edges by continuously forming and shaping metal sheets into the desired profiles.Our metal drip edge roll forming machine can be customized as your needed profile drawing .
WHAT IS DRIP EDGE AND DRIP EDGE MATERIAL
Drip edges are metal sheets, usually shaped like an “L,” installed at the edge of the roof. Also called drip edge flashing or D-metal, they serve a vital function by directing water away from the fascia and into the gutter. Without a drip edge, water may end up beneath the shingles and may cause damage to various parts of the home. Though your home may not have originally had a drip edge installed, drip edges are now required by most building codes across North America to protect homes from damage. Roof drip edges are generally sold in 10.5-foot lengths, but they are occasionally sold in 8-foot lengths or smaller. The length of the overhang itself commonly ranges from 2 to 5 inches. You may find other styles and sizes of drip edges in the store, including “J-channel” drip edges, but these are intended for windows, doors and other applications.
Type C: This is the classic“L”-shaped drip edge, sometimes called “L style.” This drip edge is bent to a 90-degree angle and has a lower flange at the bottom.
Type D: This profile of drip edge is shaped like a “T,” with a lower flange at the bottom. Sometimes it is called drip
metal, “D-metal” or “T style.” The Asphalt Roofing Manufacturers Association (ARMA) prefers this drip edge profile to Type C because it keeps the water further away from the fascia. However, Type C is still acceptable according to most building codes.
Type F: This is an extended drip edge that has a longer leading edge, which is useful when installing new drip edges over
existing shingles or on rake edges. This profile is frequently called “F style” or “gutter apron.”
metal, “D-metal” or “T style.” The Asphalt Roofing Manufacturers Association (ARMA) prefers this drip edge profile to Type C because it keeps the water further away from the fascia. However, Type C is still acceptable according to most building codes.
Type F: This is an extended drip edge that has a longer leading edge, which is useful when installing new drip edges over
existing shingles or on rake edges. This profile is frequently called “F style” or “gutter apron.”
Aluminum: A common material for drip edges, aluminum isn’t as strong as steel. It doesn’t corrode and is often sold in colors that match the rest of the home exactly.
Galvanized steel: Drip edges are designed to be in contact with water; so, if they are made of steel, they need to be galvanized to prevent rust. Minimum 24-gauge steel is preferable so that the drip edge can withstand strong winds.
Copper: Copper is a sturdy metal that gives a roof a unique look. When used as a drip edge, it should be a minimum of 0.69 mm or 20 ounces.
FEATURES AT A GLANCE
PRODUCT SPECIFICATIONS
MACHINE COMPONENTS
NO. Description Quantity
PRODUCT CONFIGURATION
Metal drip edge Roof Flashing Machine Feeding Platform
1.Features: Ensure smooth & feed material.
2.Components: steel plate platform, two pitching rollers, position stopping block.
3. The coil is guided in the correct position and passed to the roll forming equipment.
Metal drip edge Roof Flashing Machine Forming Part
14 forming stations
Cr12 rollers and solid shafts
70 mm solid shaft diameter
Cast iron machine stands
700 mm height whole iron plates welded base frame
Metal drip edge making Machine Hydraulic cutting type
Four pillar guide Hydraulic Post-cut Shear Type
cr12 material
processing technology: rough material milling machine processing - vacuum heat treatment HRC58-60 - flat grinding processing end face - wire cutting processing outline - engraving machine fine carving shape.
Metal drip edge making Machine hydraulic pump station
4 kw with cooling fan which can extend the pump station lifetime
Metal drip edge making Machine electric control cabinet
DELTA Brand PLC/ Touch Screen/ inverter
Metal drip edge making Machine decoiler
3 tons
Steel coil inner diameter, φ460㎜——540㎜ ㎜
Steel coil external diameter, maxφ1500 ㎜
Steel coil width 0--500 ㎜.
149 mm spindle which is strong
manual type
can customize do hydraulic decoiler or electric decoiler
Metal drip edge making Machine run out table
6 m length
Product packaging
SALES AND SERVICE NETWORK
Successful Project
Projectin USA
Project in Argentina
Project in Canada
RECOMMENDED PRODUCTS
CE certificate
CE Certificate
EXHIBITION AND CLIENTS
SAMPLE ROOM
FAQ
1. Package1). Container packing of the line suitable for overseas shipping
2). The subjects can be loaded by one 40ft FCL shipping.
3). Package style: Covered by plastic film, spare parts and some small parts packed in carton box.2. Delivery Time50 days (not include Chinese holiday) from order acceptance, deposit receipt and technical details agreement.3. Payment30% paid by T/T as deposit, 70% paid by T/T before loading.
4. Quality Warranty 15 months from time of loading by seller quality guarantee, life guarantee repair.
Within quality guarantee period, except for failures caused by human error, repair parts will be provided for free. After the quality guarantee period, only charge the production cost of the spare parts.
Free technical supporting and maintenance consulting in lifetime.5. Assembly (Optional)
1). Machine will be tested completely in working before delivery to you.After receiving the machine and just need to connect the main power wires and can start to work. I will send you operation video , operation manual,too. very easy to operate.2). If you need engineer overseas serviceas, the installation charge can be discuss with Elena Whastapp 0086-13231741939 If you need engineer overseas services, the buyer has to pay the seller’s technician: Travel cost outside China (Including round flight charges), accommodation and foods (At least three-star hotel with air condition), solve the language problem, provide transportation from living place to the work place, and insurance out of China, etc.
